40Gbps QSFP+ to QSFP+ Active Optical Cable (AOC)

40Gbps QSFP+ to QSFP+ Active Optical Cable

P/N: VV-QP-AOC-XXM

Consult

Product details

Description

The VV-QP-AOC-XXM is a high performance, cost effective I/O solutions for 40G LAN, HPC and SAN applications.

The QSFP+ active optic cables are a high performance, low power consumption, long reach interconnect solution supporting 40G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE P802.3ba 40GBASE-SR4.

QSFP AOC is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s.

Features

4 channels 850nm VSCEL full-duplex AOC
Transmission data rate up to 10.3Gbit/s per channel
QSFP+ Small Form Factor Compliant to SFF-8436
Maximum aggregate data rate: 40 Gb/s(4 x 10Gb/s)
Single +3.3V power supply operating
Temperature range 0°C to 70°C
I2C based two-wire serial interface
RoHS Compliant Part
Cabel length up to 70M OM3/100m OM4

Applications

40GBase Ethernet
Infiniband 4x SDR, DDR, QDR
Data centers
SAS, Servers, Hubs, Switches, Routers

Optical and Electrical Characteristics

Parameter	Symbol	Min.	Typical	Max.	Unit
Transmitter
Centre Wavelength	λc	840	850	860	nm
Spectral Width (RMS)	σ			0.65	nm
Average Output Power	Pout	-7.5		-2.5	dBm
Extinction Ratio	ER	3			dB
Average Launch Power of Off Transmitter				-30	dBm
Input Differential Impedance	Zin	90	100	110	Ω
Data Input Swing Differential	VIN	200		700	mV
Differential input voltage amplitude	ΔVin	300		1100	mVp-p
Differential output voltage amplitude	ΔVout	500		800	mVp-p
Receiver
Centre Wavelength	λc	840	850	860	nm
Receiver Sensitivity	PIN			-5.4	dBm
Receiver Overload	Pmax	0.5			dBm
LOS De-Assert	LOSD			-7.5	dBm
LOS Assert	LOSA	-30			dBm
LOS Hysteresis		0.5			dB
Data Output Swing Differential	Vout	300		800	mV
Input Logic Level High	VIH	2.0		VCC	V
Input Logic Level Low	VIL	0		0.8	V
Output Logic Level High	VOH	VCC-0.5		VCC	V
Output Logic Level Low	VOL	0		0.4	V

Ordering Information

Part No.	Product Description
VV-QP-AOC-XXM	40GBase-SR4 AOC QSFP+ to QSFP+ 1~100M MMF
XX stands for 0.5, 1, 2, 3, 4, 5...100 m(unit)
